Xbox Backup Creator Build:0306 v2.9 [TorrentX]

Xbox Backup Creator v2.9 Build:0306 by Redline99

*** NOTE ***
This build of XBC does not support older Xtreme ripping firmwares
(Kreon drives are still supported though)
Stealth Checking verbiage/intent removed, XBC only does limited checking.
Use abgx360 atfor more thorough Stealth Checking

Removed - Support for previous Xtreme ripping firmwares
Removed - Stealth Check Buttons - Use agbx360

Changed - Stealth Check Report - PFI Wave X Date match removed
Changed - Named check mark on options tab as "ISO Check"
to reflect it is not a "Stealth Check" anymore

Added - Ability to lock game partition before ripping
Added - Ability to detect iXtreme firmware spoofing
Added - Support for iXtreme 1.6 Samsung
Added - Support for iXtreme 1.6 BenQ
Added - Support for iXtreme 1.6 Liteon
Added - Support for iXtreme 1.6 Hitachi
(Note: Hitachi is untested and awaiting a firmware release)

Due to an issue that affects the Liteon ix16 it is advised that you start
XBC without a DVD in the drive.

=================================================================================
Xbox Backup Creator v2.8 Build:0275 by Redline99

Added - Added support for BenQ VAD6038 0800 firmware
(Note: This has had limited testing, be cautious)

=================================================================================
Xbox Backup Creator v2.7 Build:0265 by Redline99

Added - Support for Kreon's SH-D163B firmware
Added - Support for Kreon's SH-D162D firmware
Added - Verify Disc button on the Drive Tools Tab
Added - Added option to do a Verify Disc after a Burn
(Note: Used ImgBurns build in Verify when selected)

=================================================================================
Xbox Backup Creator v2.6 Build:0260 by Redline99

Changed - Stealth Check Report
Changed - SplitVid Implementation for better compatibility
Changed - Removed Eject/Load button from Drive Tools

Added - More information from SS to log
Added - Stealth Check for Backup media
Added - Stealth Check Before Burn process for Nero
Added - Stealth Check Before Burn process for ImgBurn
Added - Stealth Check to Validate Media ID XEX-SS-DMI
Added - SplitVid format as a public option, Default Enabled
Added - Region Check button in Drive Tools
Added - Region Check button in Image Tools
Added - Better sector caching to generic dvd reader
Added - Check and on the fly fixing for backup media info in PFI
Added - Check to validate Video size versus PFI when injecting
into an ISO and in Stealth Check

Fixed - XDVDFS Parser to read on 0x10 sector alignments

=================================================================================
Xbox Backup Creator v2.5 Build:0XXX by Redline99

Changed - Stealth Check Report
Changed - SplitVid Implementation for better compatibility
Changed - Removed Eject/Load button from Drive Tools

Added - More information from SS to log
Added - Stealth Check for Backup media
Added - Stealth Check Before Burn process for Nero
Added - Stealth Check Before Burn process for ImgBurn
Added - Stealth Check to Validate Media ID XEX-SS-DMI
Added - Media ID Check before injecting SS or DMI into an ISO Image
Added - SplitVid format as a public option, Default Enabled
Added - Region Check button in Drive Tools
Added - Region Check button in Image Tools
Added - Better sector caching to generic dvd reader
Added - Check and on the fly fixing for backup media info in PFI
Added - Check to validate Video size versus PFI when injecting
into an ISO and in Stealth Check

Fixed - XDVDFS Parser to read on 0x10 sector alignments
Fixed - Issue with reading Backups on a SHD162C somtimes

Known Issues:
The read tab is slower to enable the controls
Return Value from ImgBurn not working properly
USB Drives in ASPI mode are not recognized correctly
And a few others from previous releases with some more new ones sprinkled in
to keep me up late.

Notes:
Check your settings, this version will reset all settings back to their defaults

On the Image Tools Tab if you use the "Image Browser" it will first check if
there is a dvd in the current selected drive. If there is a dvd in the drive then
that is what will be displayed. You can use the menu in the Image Brower to
close that and open an iso file.

=================================================================================
Xbox Backup Creator v2.4 Build:0225 by Redline99

Added - Image Browser/Extractor
Right mouse click in Tree/List for extraction options
Use File menu to load an iso image from HDD
Added - Region Checking xbe/xex
Added - Support to burn image in ImgBurn (Currently doesn't get correct exit code?)
Added - Support to burn image with Nero (COM component)
Added - Support to detect identity changing between Hitachi and Samsung
I've been too lazy to hook my Hitachi back up with a modified firmware
so this has not been fully tested by myself. :)
Added - Support to Extract/Inject Video
Added - Support to read PFI, DMI, SS and whole image off of a backup
Added - Support for iso's that dont have PFI, DMI (will substitute standard values)

Changed - SPTI Timeout values, hopefully fixes more than creates problems :)
Changed - Drive Open method for burner to Exclusive Access
Changed - Changed verbiage on ISO Tools tab from Merge to Inject
Changed - Relaxed PFI check to allow for oddballs like Star Trek Legacy
Changed - Timeout value when setting layerbreak from 10 seconds to 120
Changed - Method to detect current visible partition, a little slower now though
Changed - Removed SGD-605B until I have the time to properly support it
Changed - Removed Save Firmware button, there are better tools for this
Changed - Removed Get DriveKey button, there are better tools for this

Fixed - Not being able to quit if the drive space was low and user selected cancel
Fixed - Initial lock state for Kreons drives
Fixed - File Handle not being closed after FindFirstFile
Fixed - Issue with non-standard video or game partition sizes (Star Trek Legacy)

=================================================================================
Xbox Backup Creator v2.3 Build:0185 by Redline99

Added - Support for SH-D163A using Kreon's firmware

Changed - Get Security Sector precedure to retry upto 5 times on failure
Changed - Stealth Check to include Security Sector
It also will do an additional check for Xbox One 0x0200 - 0x02CF

=================================================================================
Xbox Backup Creator v2.2 Build:0180 by Redline99

Fixed - Some drive/media combinations didn't report Available bytes correctly

Added - Option to Perform the OPC or not, Default = True
Added - Option to Perform the Track Reservation or not, Default = True
Added - Fix for Invalid Xbox One Security Sector (Kreon pre .81 and Hitachi F900)
Added - Support for Maximus-Garyopa Hitachi-LG Xtreme v2.2 Stealth 8in1 (limited)
Added - Support for Frog Aspi v0.29.4, http://www.frogaspi.org/index.html
Added - Support for TS-H943A Xtreme v4.0 Game Partition Unlock command

Changed - Set Write Speed, Hopefully more compatible
Changed - New method of monitoring the tray status
Changed - GetMediaStatus routine, to allow for more waiting after closing a disk
Changed - Increased the File IO read timeout,
this puts more responsibility on the burners buffer-underrun tech

Please start using the Frog Aspi v0.29.4 in ASPI mode. If it works for everyone
then I will probabally set that as default next time.

=================================================================================
Xbox Backup Creator v2.1 Build:0175 by Redline99

Removed - SDG-605B from being able to create a Complete Backup Image (Will bring back and fix later)
Removed - Most of the "Wait For Ever" CDB code options. This was causing what looked like a App hang.
Removed - Speed Boost check box. It is now controlled by the drop down box in the Drive Specific settings

Changed - Log File will always get the Detail Log Level unless logging is turned off
Changed - Reduced executable file size
Changed - Improved installer
Changed - Read Me file to reflect common questions and current status.

Fixed - ToolTip text for the Merge/Extract on the Image Tools Tab
Fixed - Burner didn't write at selected speed
Fixed - Error on Windows 2000 related to "uxtheme.dll"
Fixed - DeviceIoControl Error when extracting Security Sector with SH-D162C (Experimental; not proven)

Added - More detailed logging of operations and results
Added - Hopefully some better writer compatibility (I can't really test)
Added - New logo by jhyphinwill, Thanks looks nice and it got me away from the Microsoft logo :)
Added - New Read error reporting that will tell you the file name of the data it can't read
Added - Check of the OS before using theme dll (uxtheme.dll)
Added - Additional Inquiry data (Nice for Kreon’s SH-D162C, shows version info)
Added - New dialog when a read error occurs (Allows Retry, Fill with zeros, Cancel)
Added - Should a file buffer error occur during writing, it will retry 10 times before failing
Added - Code to prevent multiple instances of the application
Added - Warning if the drive is already unlocked when doing a Complete Backup
Added - Better overall retry strategy when Initializing/Writing/Finalizing)
Added - A detailed Security Sector log
Added - Check of image file size before writing
Added - Optimum Power Calibration before writing
Added - Log file will now reset if larger than a 512KB
Added - New method for reading Xbox One disks. This should greatly improve the process. See Note *
Added - Feature to save the XDVDFS structure to a comma delimited text file (mostly for research)
Added - XDVDFS File system entry details (if a read error is in the file system area)
Added - Feature that if user selects to fill read errors with zeros, but a
read error occurs in file system data they will get prompted again as this
could be a media defect error in game data and shouldn't just be filled with zeros.

-------------------------------------------------------------------------------------------
* This uses a technique I called the "Sector Mapper" It uses the XDVDFS to read only the
data referenced by the file system. In theory this should do two things:
1. Speed up the process by not trying to read the Security Place Holders
2. Speed up the process by only reading the data, not the entire disk.
Please be aware that although this has been tested and is working the concept has
not proven itself on a large scale. It currently does not work on Xbox 360 disks.
-------------------------------------------------------------------------------------------

Xbox Backup Creator v2.0 Build:0100 by Redline99
Initial Release

-------------------------------------------------------------------------------------------
-------------------------------------------------------------------------------------------
Hardware Requirements:
Processor: Something within the last 3 years should be fine. I use a P4 3GHz with 1GB Ram
Ram: The application currently used a 20MB write buffer, shouldn’t be a
problem on current machines.
Drives: A DVD+R Double Layer burner that supports a Buffer Underrun Technology.
PC DVD Samsung SH-D162C with Kreons modified firmware (PC DVD Drive)**
Xbox 360 Samsung TS-H943A with Xtreme compatible firmware, v1, v2 or v3.
Xbox 360 Hitachi GDR-3120L with Xtreme compatible firmware with OPA v2.1***

OS Requirements:
Windows NT platform with NTFS file system (because file sizes are 4+ GB)
Windows XP SP2 is preferred, Vista has not been tested.
If there is enough interest I may support Win9x by way of creating file sets
within FAT32 limits. An ASPI driver will also be required. (ASPI already
